Self-adhesive OnMold RFID-labels
Permanent labeling solution: UHF and HF inlays embedded in sturdy and media-resistant polyester laminate
Readability without direct visual contact and a reduced dependency on cleanliness are two key benefits of RFID technology in numerous operations – whether in intralogistics, industrial production, or other primarily automated goods cycles and supply chains.
PMG OnMold RFID labels guarantee a reliable, individual and durable labeling of objects
This is where OnMold RFID labels from PMG Labels LP shine. Regardless of their surroundings, they excel in durability, weather resistance, robustness, and machine readability – ensuring secure, long-term identification of objects tailored to your needs.
Peel-resistant adhesion, tough surface, high resistance
OnMold RFID-labels enable the long-term identification of objects such as boxes, containers, pallets, storage areas and other logistics assets. High adhesion reliability is guaranteed – the peeling resistance is 38 N at 25 mm – thanks to a synthetic, permanently adhesive hybrid glue coating the underside of the labels.
It reliably ensures that the label always remains on the object – even on high and low-energy surfaces such as glass, PP (polypropylene), PE (polyethylene) or ABS.
The format of OnMold RFID-labels from PMG is freely selectable and can be optimally adjusted to suit the application. A transparent, scratch and wipe-proof, UV-resistant laminate film is applied to the top of the label’s tough polyester basic laminate.
This surface protects the optional label print which can be individually designed with barcodes, numbers, digits, characters and logos. The RFID module – with a choice of UHF inlays (EPC class 1 gen. 2, 860 - 960 MHz) or HF inlays (13.56 MHz) is embedded in the basic laminate and reliably protected there against external influences.
OnMold RFID labels can be read at distances between 19.68 inch and 1 ½ ft / 0.5 m and 55 ft / 17 m using stationary and mobile RFID readers from the widest range of manufacturers.
The temperature resistance of PMG OnMold RFID labels is specified at 40 °F to +275 °F (-40 °C to +135 °C) – and even briefly up to +320 °F (+ 160 °C). The chip itself is specified for up to +185 °F (+85 °C). As a result, the labels can remain on the object in deep-freeze applications, in high-temperature washing and drying processes, or other thermally demanding environments.
Other features of OnMold RFID labels from PMG:
- The format is freely selectable and can be optimally adjusted to suit the application.
- The label exhibits excellent adhesive qualities at temperatures ranging from -40 °F to +275 °F (-40 °C to +135 °C).
- A transparent, scratch and wipe-proof, UV-resistant laminate film is applied to the top of the label's tough polyester base material.
- Especially suitable for apolar, low-energy substrates, such as PP, PE, and HDPE.
- Freely selectable formats and inlays (HF/UHF).
- Available with full-color printing or black & white.
- Full customization and encoding options.
- Complies with food contact regulations.
- Moisture-resistant and watertight.
- Resistant to a wide range of acids, alkalis, solvents, industrial cleaning agents, and disinfectants.
- Suitable for extreme outdoor use with direct exposure to the sun, rain, frost, and snow.
- Exposure/weathering tests confirm high resistance to environmental influences according to EN ISO 11341 cycle A (exposure) and C (weathering).
- Fungal-resistant, non-fungal-promoting.
- All materials used meet the requirements of REACH regulation 1907/2006/EG and the current RoHS guidelines.
Typical areas of application
The OnMold RFID-labels from PMG are supplied on rolls – either blank for subsequent printing by the customer or, if required, already printed and serialized. They guarantee a reliable permanent identification of containers, pallets, shelf compartments, storage spaces, pipes, operating materials and other mobile assets in intralogistics, in industrial assembly and manufacturing processes, and in a range of industries.
Sizes - individual sizes on request
| 4.05x0.78 inch | 3.94x1.97 inch | 3.94x1.18 inch | 3.74x0.75 inch | 2.28x1.50 inch |
|---|---|---|---|---|
| 102x20 mm | 100x50 mm | 100x30 mm | 95x19 mm | 58x38 mm |
Industry sectors:
container labeling, pallet labeling, inventory labeling, storage rack labeling, the medical or logistics sector, and many other industrial applications
