PMG RFID Works on Metal - specially developed for high performance on metal surfaces

The PMG RFID works on Metal label is specially designed for direct connection of RFID technology on metallic surfaces. This can be easily integrated into your existing RFID system and enables asset tracking of metal plates, metal pipes, dollies, reusable metal goods and containers.

Permanent connection to the base carrier through RFID metal labels


The label on polyester (PET) basis, which is provided with an acrylate adhesive, is characterized by an extraordinary robustness. Due to the low height of the RFID tags (1 mm), the label has the property to ensure excellent adhesion on curved as well as irregularly shaped surfaces.

Our "RFID works on metal" label is extremely resistant to environmental influences such as moisture, water, heat, acids or alkalis. The application of the label on metal takes place with the above mentioned strongly adhesive acrylate glue. The permanent connection to the base carrier is thus guaranteed.

We produce our "RFID works on Metal" with a UHF chip (EPC Class 1 Gen 2, 860 - 960 MHz) as standard. Other chip types are of course possible on request. Despite the low height, ranges of up to approx. 5 m on metal can be achieved (at 2 W ERP reader power).


Many possible applications for PMG's Works on Metal RFID labels:

  • Plant marking
  • Pallet marking
  • Container marking
  • Storage rack marking
  • Container marking
  • and other industrial applications where the materials are exposed to high loads


Our PMG RFID works on Metal tags are equally suitable for petrochemical applications and the automotive sector. Since these labels in particular are very robust, they can be used for any security application.

Easy application on most surfaces, anti-collision, thus problem-free bulk detection and a favorable price characterize our RFID works on Metal.


Here are the benefits of our PMG works on Metal RFID-label summarized:


  • The PMG RFID Works on Metal RFID labels were specially designed to deliver high performance on metal surfaces
  • Thanks to its low structural depth 0.04 inch / 1 mm, it guarantees excellent adhesion to curved and irregular shaped metal components
  • Despite its low depth, ranges of up to approx. 16 ft / 5 m are possible on metal (at a 2 W ERP reader output)
  • Our standard “Works on Metal” is produced with a UHF chip (EPC Class 1 Gen 2, 860 – 960 MHz) – other types of chips are available on request
  • The very tough label properties also make them suitable for use in harsh environments
  • Individual serialization possible
  • Available with full color printing or black & white
  • Printing protected under laminate including UV and IR protection optionally available
  • Full customization and encoding options
  • Adhesive optimized for metals


For more information, please contact us via e-mail info@pmglabels.com or simply give us a call at +1 480 400 93 57. We will be happy to advise you!


Industry sectors:

container labeling, pallet labeling, systems labeling, warehouse rack labeling
